Daihatsu Rocky ja Romania

[LaaLaa]

Hi Christian,
Google translator is so bad that it's impossible to understand your message correctly.
Please write your messages in english, most of the peaople here understand it better than google translator chaos.

If I understood right, you asked about good coil spring alternatives for your Daihatsu Rocky? MB124 coil spring might be good for Rocky. Vitara front coils might be too stiff and rear coils too soft.

[AlluK]

Dracula car

[Mojoman]

Transylvanian Express

Welcome to the Forum!

[Cristian1]

I want to put W124 springs in front and rear Vitara front. It's here on the forum any Rocky converted to coils, but has original axles?
Worries me distance between spindle and chassis. It is very small (~ 11cm) and the W coils, has 98mm diameter...

Yes, @AlluK, I live at 40 km from Sighisoara city of Dracula, there is a strong off-road club.

[LaaLaa]

Can you cut some material away from frame and make a spring cup from right size metal tube? That way you could move spring few cm away from spindle/knuckle. Like this how I made it for my Suzuki lwb (weldings are just for test fitting in pic)

[Cristian1]

Interesting method! But I think it's too risky in front of Rocky because is support of Panhard bar and after, is the support of the engine ... But is good method !
Regarding the type of suspension I have a dilemma ...
-To put radius arms on Pajero / Defender
-Or 3link. But 3 link + Panhard is ok if you fixed in the same point with upper link and lower link bolt ?

[LaaLaa]

If you use heavy wall thikness tube and make enough support brackets, it might be strong enough for front also.

Radius arms are ok in front suspension but they are not flexing so much if you like extreme suspension travel. But compared to leaf springs, improvement will be huge.

3-link is not good with uppel and lower links connected in same bolt in frame side. Think about hard braking on asphalt and what direction forces go in the links. If connected in same bolt, it will try to lift that connection point straight up. And when it's connectetd only at other side frame rail, it will lift only other side of you car. That will effect other side tires to have more traction and you can imagine what happens next...

Believe me, I have tested it by disconnectiing one front axle side bolt from radius arm suspension (in suzuki, heavy cars like Defender might not be so sensitive for that steering effect)

Remember, that you can make front upper link shorter and in the angle like XJ Cherokee. That way you might get your 3-link front suspnsion fitted to Rocky. And by separating connection point in upper link frame side you will get much less uplifting effect

[Jeeper]

One option is to use "x-link" with radius arms.
I think that someone tried this in offipalsta?, Can´t remember who
